Part Number | TCMD4000 |
---|---|
Manufacturer | Vishay |
Quantity in stock | 671170 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Optocoupler DC-IN 4-CH Darlington DC-OUT 16-Pin Mini-Flat |
Category | Optoelectronics |
Family | OptoCouplers |
ROHS Compliant | Yes |
MSL Level | TCMD4000 |
Datasheet download | ![]() |
Part Number | TCMD4000 |
---|---|
Supplier Package | Mini-Flat |
Maximum Collector Current | 80 mA |
Maximum Power Dissipation | 250 |
Rad Hard | No |
Product Dimensions | 10.12 x 4.4 x 1.9 mm |
Maximum Reverse Voltage | 6 |
Operating Temperature | -40 to 100 °C |
Maximum Input Current | 60 mA |
Minimum Isolation Voltage | 3750 |
Maximum Collector Emitter Voltage | 35 V |
Number of Channels per Chip | 4 |
Mounting | Surface Mount |
Lead Finish | Matte Tin |
Pin Count | 16 |
MSL Level | 1 |
Maximum Current Transfer Ratio @ Current | 800 % |
Maximum Collector Emitter Saturation Voltage | 1000 |
Max Processing Temp | 240|260 |
Output Type | DC |
Maximum Forward Voltage | 1.6 |
Input Type | DC |
Typical Forward Voltage | 1.25 |
Package | 16Mini-Flat |
Replacement Part Number | PART-TCMD4000 |
Weight | Contact us |
Country of Origin | - |
