PTN78020WAZ Texas Instruments

PTN78020WAZ Images

Please contact us for more photos of PTN78020WAZ

Part Number PTN78020WAZ
Manufacturer Texas Instruments
Quantity in stock 866210 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Module DC-DC 1-OUT 2.5V to 12.6V 6A 90W 7-Pin DIP Module
Category Power Supplies
Family DC to DC Power Supply
ROHS Compliant Yes
MSL Level PTN78020WAZ
Datasheet download PTN78020WAZ.pdf
Request Quotation for PTN78020WAZ

PTN78020WAZ Specifications

Part Number PTN78020WAZ
Type Step Down
Rad Hard No
Max Processing Temp 260
Pin Count 7
MSL Level 3
Supplier Package DIP Module
Mounting Surface Mount
Output Power 90 W
Switching Regulator Yes
Number of Outputs 1
Input Voltage 7 to 36 V
Output Voltage 2.5 to 12.6 V
Output Current 6 A
Product Dimensions 37.97 x 22.1 x 8.75 mm
Package 7DIP Module
Replacement Part Number PART-PTN78020WAZ
Weight Contact us
Country of Origin -
