Please contact us for more photos of EBDW020A0B641-HZ
| Part Number | EBDW020A0B641-HZ |
|---|---|
| Manufacturer | GE Critical Power |
| Quantity in stock | 491880 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 12V 20A 240W 15-Pin 1 8-Brick Tray |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | EBDW020A0B641-HZ |
| Datasheet download |  EBDW020A0B641-HZ.pdf |
| Part Number | EBDW020A0B641-HZ |
|---|---|
| Lead Finish | Matte Tin |
| Max Processing Temp | 270 |
| Number of Outputs | 1 |
| Output Current | 20 A |
| Mounting | Through Hole |
| Supplier Package | 1/8-Brick |
| Switching Regulator | Yes |
| MSL Level | 2a |
| Output Power | 240 W |
| Product Dimensions | 22.8 x 58.4 x 12.77 - 0.38 mm |
| Rad Hard | No |
| Output Voltage | 12 V |
| Pin Count | 15 |
| Package | 151/8-Brick |
| Replacement Part Number | PART-EBDW020A0B641-HZ |
| Weight | Contact us |
| Country of Origin | - |
