Please contact us for more photos of PTH08T255WAD
| Part Number | PTH08T255WAD |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 490190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 3V to 5.25V 40A 22-Pin DIP Module Tray |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | PTH08T255WAD |
| Datasheet download |  PTH08T255WAD.pdf |
| Part Number | PTH08T255WAD |
|---|---|
| Input Voltage | 8 to 14 V |
| Type | Step Down |
| Number of Outputs | 1 |
| Mounting | Through Hole |
| Switching Regulator | Yes |
| Pin Count | 22 |
| Supplier Package | DIP Module |
| Product Dimensions | 38.61 x 25.91 x 9.64 mm |
| Rad Hard | No |
| Output Current | 40 A |
| Output Voltage | 3 to 5.25 V |
| Package | 22DIP Module |
| Replacement Part Number | PART-PTH08T255WAD |
| Weight | Contact us |
| Country of Origin | - |
