PTH08T250WAD Texas Instruments

PTH08T250WAD Images

Please contact us for more photos of PTH08T250WAD

Part Number	PTH08T250WAD
Manufacturer	Texas Instruments
Quantity in stock	519100 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Module DC-DC 1-OUT 0.7V to 3.6V 50A 22-Pin DIP Module Tray
Category	Power Supplies
Family	DC to DC Power Supply
ROHS Compliant	Yes
MSL Level	PTH08T250WAD
Datasheet download	PTH08T250WAD.pdf

Request Quotation for PTH08T250WAD

PTH08T250WAD Specifications

Part Number	PTH08T250WAD
Product Dimensions	38.61 x 25.91 x 9.64 mm
Output Voltage	0.7 to 3.6 V
Rad Hard	No
Max Processing Temp	235\|260
MSL Level	1\|3
Supplier Package	DIP Module
Type	Step Down
Output Current	50 A
Number of Outputs	1
Switching Regulator	Yes
Mounting	Through Hole
Pin Count	22
Input Voltage	4.5 to 14 V
Lead Finish	Tin
Package	22DIP Module
Replacement Part Number	PART-PTH08T250WAD
Weight	Contact us
Country of Origin	-
