PTH05000WAS Texas Instruments

PTH05000WAS Images

Please contact us for more photos of PTH05000WAS

Part Number PTH05000WAS
Manufacturer Texas Instruments
Quantity in stock 889970 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Module DC-DC 1-OUT 0.9V to 3.6V 6A 5-Pin DIP Module
Category Power Supplies
Family DC to DC Power Supply
ROHS Compliant Yes
MSL Level PTH05000WAS
Datasheet download PTH05000WAS.pdf
Request Quotation for PTH05000WAS

PTH05000WAS Specifications

Part Number PTH05000WAS
Rad Hard No
Mounting Surface Mount
MSL Level 1
Supplier Package DIP Module
Number of Outputs 1
Input Voltage 5(TYP) V
Switching Regulator Yes
Pin Count 5
Product Dimensions 18.92 x 12.57 x 8.25 mm
Type Step Down
Output Current 6 A
Lead Finish Tin/Lead
Output Voltage 0.9 to 3.6 V
Max Processing Temp 235
Package 5DIP Module
Replacement Part Number PART-PTH05000WAS
Weight Contact us
Country of Origin -
