Please contact us for more photos of ADS8372IBRHPT
| Part Number | ADS8372IBRHPT |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 226300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 600ksps 16-bit Serial 28-Pin VQFN EP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADS8372IBRHPT |
| Datasheet download |  ADS8372IBRHPT.pdf |
| Part Number | ADS8372IBRHPT |
|---|---|
| Differential Nonlinearity | ±0.5 LSB |
| Single-Ended Input | Yes |
| MSL Level | 2 |
| Resolution | 16 Bit |
| Lead Finish | Gold |
| Number of ADCs | 1 |
| Input Voltage | ±4.2 V |
| Typical Power Dissipation | 110 mW |
| Full Scale Error | 0.075 % of FSR |
| Polarity of Input Voltage | Bipolar |
| Differential Input | Yes |
| Maximum Single Supply Voltage | 5.25 V |
| No Missing Codes | 16 Bit |
| Digital Supply Support | Yes |
| Voltage Supply Source | Analog and Digital |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Digital Interface Type | Serial (SPI) |
| Supplier Package | VQFN EP |
| Number of Analog Inputs | 1 |
| Minimum Single Supply Voltage | 4.75 V |
| Signal to Noise Ratio | 93.5 dB |
| Input Type | Voltage |
| Input Signal Type | Single-Ended|Differential |
| Architecture | SAR |
| Mounting | Surface Mount |
| Pin Count | 28 |
| Voltage Reference | Internal |
| Product Dimensions | 6 x 6 x 0.9 mm |
| Sample and Hold | Yes |
| Typical Single Supply Voltage | 5 V |
| Integral Nonlinearity Error | ±0.75 LSB |
| Screening Level | Industrial |
| Sampling Rate | 600 ksps |
| Package | 28VQFN EP |
| Replacement Part Number | PART-ADS8372IBRHPT |
| Weight | Contact us |
| Country of Origin | - |
