ADS1271IBPWR Texas Instruments

ADS1271IBPWR Images

Please contact us for more photos of ADS1271IBPWR

Part Number ADS1271IBPWR
Manufacturer Texas Instruments
Quantity in stock 225470 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description ADC Single Delta-Sigma 105ksps 24-bit Serial 16-Pin TSSOP T R
Category Data Conversion IC
Family ADC
ROHS Compliant Yes
MSL Level ADS1271IBPWR
Datasheet download ADS1271IBPWR.pdf
Request Quotation for ADS1271IBPWR

ADS1271IBPWR Specifications

Part Number ADS1271IBPWR
Digital Interface Type Serial (SPI)
Screening Level Extended Industrial
Single-Ended Input No
Differential Input Yes
Maximum Single Supply Voltage 5.25 V
Input Type Voltage
Number of ADCs 1
Input Signal Type Differential
Input Voltage ±2.5 V
Architecture Delta-Sigma
Integral Nonlinearity Error 0.0015 % of FSR
Full Scale Error 0.5 % of FSR
Maximum Power Dissipation 136 mW
Sampling Rate 105 ksps
Typical Power Dissipation 92 mW
Signal to Noise Ratio 109 dB
Differential Nonlinearity ±1 LSB
Digital Supply Support Yes
Pin Count 16
Operating Temperature -40 to 105 °C
Polarity of Input Voltage Bipolar
Sample and Hold No
No Missing Codes 24 Bit
Resolution 24 Bit
Voltage Reference External
Product Dimensions 5.1 x 4.5 x 1.05 mm
Number of Analog Inputs 1
Supplier Package TSSOP
Voltage Supply Source Analog and Digital
Minimum Single Supply Voltage 4.75 V
Typical Single Supply Voltage 5 V
Mounting Surface Mount
MSL Level 2
Lead Finish Gold
Rad Hard No
Max Processing Temp 260
Package 16TSSOP
Replacement Part Number PART-ADS1271IBPWR
Weight Contact us
Country of Origin -
