Please contact us for more photos of 280377-1
| Part Number | 280377-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 320170 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 2 POS 2.54mm Solder RA Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 280377-1 |
| Datasheet download |  280377-1.pdf |
| Part Number | 280377-1 |
|---|---|
| Body Orientation | Right Angle |
| Housing Material | Thermoplastic |
| Contact Plating | Tin |
| Pitch | 2.54 mm |
| Max Processing Temp | 240|260|265 |
| Product Dimensions | 7.7 x 14.9 x 5 mm |
| Rad Hard | No |
| Operating Temperature | -55 to 105 °C |
| Contact Material | Phosphor Bronze |
| Mounting | Through Hole |
| Gender | HDR |
| Termination Method | Solder |
| Product Depth | 14.9 mm |
| Product Height | 5 mm |
| Product Length | 7.7 mm |
| Replacement Part Number | PART-280377-1 |
| Weight | Contact us |
| Country of Origin | - |
