Please contact us for more photos of 2-644489-3
| Part Number | 2-644489-3 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 336860 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 3 POS 2.54mm Solder RA Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 2-644489-3 |
| Datasheet download |  2-644489-3.pdf |
| Part Number | 2-644489-3 |
|---|---|
| Lead Finish | Matte Tin |
| Housing Color | White |
| Maximum Current Rating | 5/Contact |
| Termination Method | Solder |
| Gender | HDR |
| Mounting | Through Hole |
| Max Processing Temp | 240 |
| Type | Shrouded Header |
| Body Orientation | Right Angle |
| Pitch | 2.54 mm |
| Contact Material | Copper Alloy |
| Housing Material | Polyester |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Number of Rows | 1 |
| Product Dimensions | 9.75 x 10.41 x 7.95 mm |
| Maximum Voltage Rating | 250 |
| Maximum Contact Resistance | 6 |
| Operating Temperature | -55 to 105 °C |
| Product Depth | 10.41 mm |
| Product Height | 7.95 mm |
| Product Length | 9.75 mm |
| Replacement Part Number | PART-2-644489-3 |
| Weight | Contact us |
| Country of Origin | - |
