Part Number | 0038001440 |
---|---|
Manufacturer | Molex |
Quantity in stock | 423210 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Socket Strip RCP 20 POS 2.54mm Solder ST Thru-Hole Tray |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 0038001440 |
Datasheet download | ![]() |
Part Number | 0038001440 |
---|---|
Operating Temperature | 0 to 75 °C |
Contact Material | Phosphor Bronze |
Product Dimensions | 50.7 x 7.7 x 7.9 mm |
Pitch | 2.54 mm |
Max Processing Temp | 235 |
Housing Color | White |
Termination Method | Solder |
Housing Material | Nylon |
Body Orientation | Straight |
Gender | RCP |
Contact Plating | Tin |
Mounting | Through Hole |
Lead Finish | Tin |
Product Depth | 7.7 mm |
Product Height | 7.9 mm |
Product Length | 50.7 mm |
Replacement Part Number | PART-0038001440 |
Weight | Contact us |
Country of Origin | - |
