Part Number | 175286-5 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 198750 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Contact PIN Crimp ST Cable Mount Reel |
Category | Connectors |
Family | Connector Contacts |
ROHS Compliant | Yes |
MSL Level | 175286-5 |
Datasheet download | ![]() |
Part Number | 175286-5 |
---|---|
Family Name | Dynamic Series Wire-Applied Connectors |
Wire Size | 16 to 20 AWG |
Contact Type | Signal |
Mounting | Cable Mount |
Rad Hard | No |
Contact Material | Copper Alloy |
Series Name | D-3 |
Product Dimensions | 25.3 x 4.2 x 4 mm |
Shielded | No |
Connector Type | Connector Power |
Body Orientation | Straight |
Lead Finish | Tin |
Gender | PIN |
Termination Method | Crimp |
Contact Plating | Tin |
Product Depth | 4.2 mm |
Product Height | 4 mm |
Product Length | 25.3 mm |
Replacement Part Number | PART-175286-5 |
Weight | Contact us |
Country of Origin | - |
