Please contact us for more photos of 1-1318300-6
| Part Number | 1-1318300-6 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 124970 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 6 POS 3.96mm Solder ST Thru-Hole Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 1-1318300-6 |
| Datasheet download |  1-1318300-6.pdf |
| Part Number | 1-1318300-6 |
|---|---|
| Housing Material | Polybutylene Terephthalate |
| Maximum Contact Resistance | 20 |
| Contact Plating | Tin |
| Rad Hard | No |
| Housing Color | Natural |
| Operating Temperature | -25 to 105 °C |
| Termination Method | Solder |
| Lead Finish | Tin |
| Body Orientation | Straight |
| Product Dimensions | 23.7 x 8.5 x 9.2 mm |
| Pitch | 3.96 mm |
| Max Processing Temp | 240|260|265 |
| Type | Wire to Board |
| Gender | HDR |
| Contact Material | Brass |
| Number of Rows | 1 |
| Mounting | Through Hole |
| Product Depth | 8.5 mm |
| Product Height | 9.2 mm |
| Product Length | 23.7 mm |
| Replacement Part Number | PART-1-1318300-6 |
| Weight | Contact us |
| Country of Origin | - |
