Please contact us for more photos of 0431604305
| Part Number | 0431604305 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 265060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 5 POS 7.49mm Solder ST Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0431604305 |
| Datasheet download |  0431604305.pdf |
| Part Number | 0431604305 |
|---|---|
| Termination Method | Solder |
| Body Orientation | Straight |
| Lead Finish | Tin |
| Contact Plating | Tin Over Copper |
| Product Dimensions | 43.56 x 13.38 x 14.76 mm |
| Housing Color | Black |
| Mounting | Through Hole |
| Contact Material | Brass |
| Gender | HDR |
| Pitch | 7.49 mm |
| Operating Temperature | -40 to 75 °C |
| Max Processing Temp | 235 |
| Housing Material | Nylon 4/6 |
| Product Depth | 13.38 mm |
| Product Height | 14.76 mm |
| Product Length | 43.56 mm |
| Replacement Part Number | PART-0431604305 |
| Weight | Contact us |
| Country of Origin | - |
