Please contact us for more photos of B32652A2222J189
| Part Number | B32652A2222J189 |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 767130 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.0022uF 2000V PP 5% (18 X 7 X 12.5mm) Radial 15mm 100\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | B32652A2222J189 |
| Datasheet download |  B32652A2222J189.pdf |
| Part Number | B32652A2222J189 |
|---|---|
| Package/Case | 18(Max) X 7(Max) X 12.5(Max) |
| Product Dimensions | 18 x 7 x 12.5 mm |
| Lead Pitch For Radial | 15 mm |
| Dielectric Material | PP |
| Termination Style | Radial |
| Mounting | Through Hole |
| Rad Hard | No |
| Voltage(DC) | 2 kV |
| Tolerance | 5 % |
| Max Processing Temp | 260 |
| Operating Temperature | -55 to 100 °C |
| Capacitance Value | 0.0022 uF |
| Dielectric | PP |
| Voltage(AC) | 700 V |
| Seated Plane Height | 12.5 mm |
| Lead Finish | Matte Tin |
| Product Depth | 7(Max) mm |
| Product Height | 12.5(Max) mm |
| Product Length | 18(Max) mm |
| Replacement Part Number | PART-B32652A2222J189 |
| Weight | Contact us |
| Country of Origin | - |
