Please contact us for more photos of STPS15L30CB-TR
| Part Number | STPS15L30CB-TR |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 591880 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 30V 15A 3-Pin(2+Tab) DPAK T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | STPS15L30CB-TR |
| Datasheet download |  STPS15L30CB-TR.pdf |
| Part Number | STPS15L30CB-TR |
|---|---|
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Peak Average Forward Current | 15 A |
| Configuration | Dual Common Cathode |
| MSL Level | 1 |
| Product Dimensions | 6.6 x 6.2 x 2.4 mm |
| Pin Count | 3 |
| Peak Forward Voltage | 0.57 V |
| Peak Non-Repetitive Surge Current | 75 A |
| Supplier Package | DPAK |
| Rad Hard | No |
| Peak Reverse Repetitive Voltage | 30 V |
| Peak Reverse Current | 1000 uA |
| Max Processing Temp | 260 |
| Type | Schottky Diode |
| Operating Temperature | -65 to 150 °C |
| Package | 3DPAK |
| Replacement Part Number | PART-STPS15L30CB-TR |
| Weight | Contact us |
| Country of Origin | - |
