Please contact us for more photos of PMEG3005AESFYL
| Part Number | PMEG3005AESFYL |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 472630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Barrier Rectifier 30V 0.5A 2-Pin DSN T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | PMEG3005AESFYL |
| Datasheet download |  PMEG3005AESFYL.pdf |
| Part Number | PMEG3005AESFYL |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Max Processing Temp | 260 |
| Configuration | Single |
| Peak Reverse Recovery Time | 1.37 ns |
| Supplier Package | DSN |
| Peak Non-Repetitive Surge Current | 4 A |
| Pin Count | 2 |
| Peak Reverse Repetitive Voltage | 30 V |
| Peak Forward Voltage | 0.63 V |
| Operating Temperature | -55 to 150 °C |
| Product Dimensions | 0.625(Max) x 0.325(Max) x 0.29(Max) |
| Type | Schottky Barrier Rectifier |
| Peak Average Forward Current | 0.5@Ta=105C A |
| Peak Reverse Current | 80 uA |
| Package | 2DSN |
| Replacement Part Number | PART-PMEG3005AESFYL |
| Weight | Contact us |
| Country of Origin | - |
