LBAV99LT1G Leshan Radio

LBAV99LT1G Images

Please contact us for more photos of LBAV99LT1G

Part Number LBAV99LT1G
Manufacturer Leshan Radio
Quantity in stock 182790 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Switching 70V 0.215A 3-Pin SOT-23 T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level LBAV99LT1G
Datasheet download LBAV99LT1G.pdf
Request Quotation for LBAV99LT1G

LBAV99LT1G Specifications

Part Number LBAV99LT1G
Peak Reverse Repetitive Voltage 70 V
Configuration Dual Series
Operating Temperature -65 to 150 °C
Type Switching Diode
Peak Non-Repetitive Surge Current 2 A
Peak Average Forward Current 0.215 A
Rad Hard No
Mounting Surface Mount
Supplier Package SOT-23
Peak Reverse Current 2.5 uA
Product Dimensions 2.9 x 1.3 x 0.94 mm
Peak Reverse Recovery Time 6 ns
Pin Count 3
Peak Forward Voltage [email protected] V
Package 3SOT-23
Replacement Part Number PART-LBAV99LT1G
Weight Contact us
Country of Origin -
