Please contact us for more photos of MBR130T3G
| Part Number | MBR130T3G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 629090 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 30V 1A 2-Pin SOD-123 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MBR130T3G |
| Datasheet download |  MBR130T3G.pdf |
| Part Number | MBR130T3G |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 2.69 x 1.6 x 1.12 mm |
| Peak Reverse Current | 60 uA |
| Mounting | Surface Mount |
| Peak Average Forward Current | 1 A |
| Supplier Package | SOD-123 |
| Operating Temperature | -65 to 125 °C |
| MSL Level | 1 |
| Peak Non-Repetitive Surge Current | 5.5 A |
| Pin Count | 2 |
| Peak Reverse Repetitive Voltage | 30 V |
| Rad Hard | No |
| Configuration | Single |
| Max Processing Temp | 260 |
| Type | Schottky Diode |
| Peak Forward Voltage | 0.47 V |
| Package | 2SOD-123 |
| Replacement Part Number | PART-MBR130T3G |
| Weight | Contact us |
| Country of Origin | - |
