Please contact us for more photos of BAT54S,215
| Part Number | BAT54S,215 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 875800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 30V 0.2A 3-Pin TO-236AB T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAT54S,215 |
| Datasheet download |  BAT54S,215.pdf |
| Part Number | BAT54S,215 |
|---|---|
| Pin Count | 3 |
| Rad Hard | No |
| Peak Reverse Current | 2@25V uA |
| Peak Forward Voltage | [email protected] V |
| Configuration | Dual Series |
| Peak Reverse Repetitive Voltage | 30 V |
| Lead Finish | Tin |
| Operating Temperature | -55 to 150 °C |
| Type | Schottky Diode |
| Peak Reverse Recovery Time | 5 ns |
| Product Dimensions | 3 x 1.4 x 1 mm |
| Peak Non-Repetitive Surge Current | 0.6 A |
| Peak Average Forward Current | 0.2 A |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Supplier Package | TO-236AB |
| Mounting | Surface Mount |
| Package | 3TO-236AB |
| Replacement Part Number | PART-BAT54S,215 |
| Weight | Contact us |
| Country of Origin | - |
