Please contact us for more photos of BYQ72EK-200Q
| Part Number | BYQ72EK-200Q |
|---|---|
| Manufacturer | WeEn Semiconductors |
| Quantity in stock | 561290 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Ultrafast Power Diode 200V 15A 3-Pin TO-3P Rail Pack |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BYQ72EK-200Q |
| Datasheet download |  BYQ72EK-200Q.pdf |
| Part Number | BYQ72EK-200Q |
|---|---|
| Mounting | Through Hole |
| Pin Count | 3 |
| Rad Hard | No |
| Peak Forward Voltage | 1.2@30A V |
| Operating Temperature | -40 to 150 °C |
| Peak Reverse Repetitive Voltage | 200 V |
| Lead Finish | Tin |
| Max Processing Temp | 260 |
| Configuration | Dual Common Cathode |
| Peak Average Forward Current | 15 A |
| Product Dimensions | 15.8(Max) x 5(Max) x 20.1(Max) |
| Supplier Package | TO-3P |
| Type | Ultrafast Power Diode |
| Peak Non-Repetitive Surge Current | 220 A |
| Peak Reverse Recovery Time | 25 ns |
| Peak Reverse Current | 20@600V uA |
| Package | 3TO-3P |
| Replacement Part Number | PART-BYQ72EK-200Q |
| Weight | Contact us |
| Country of Origin | - |
