Please contact us for more photos of BAT46WH,115
| Part Number | BAT46WH,115 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 788110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 100V 0.25A 2-Pin SOD-123F T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAT46WH,115 |
| Datasheet download |  BAT46WH,115.pdf |
| Part Number | BAT46WH,115 |
|---|---|
| Peak Reverse Recovery Time | 5.9 ns |
| Supplier Package | SOD-123F |
| Peak Forward Voltage | 0.85 V |
| Peak Reverse Current | 9 uA |
| Peak Non-Repetitive Surge Current | 2.5 A |
| Max Processing Temp | 260 |
| Product Dimensions | 2.7 x 1.7 x 1.2 mm |
| Type | Schottky Diode |
| Pin Count | 2 |
| Configuration | Single |
| Rad Hard | No |
| Peak Average Forward Current | 0.25 A |
| Mounting | Surface Mount |
| Peak Reverse Repetitive Voltage | 100 V |
| Lead Finish | Tin |
| Operating Temperature | -55 to 150 °C |
| MSL Level | 1 |
| Package | 2SOD-123F |
| Replacement Part Number | PART-BAT46WH,115 |
| Weight | Contact us |
| Country of Origin | - |
