Please contact us for more photos of ECWHA3C103J
| Part Number | ECWHA3C103J |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 123850 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.01uF 1600V PP 5% (20.3 X 6.4 X 12.3mm) Radial 17.5mm 105\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECWHA3C103J |
| Datasheet download |  ECWHA3C103J.pdf |
| Part Number | ECWHA3C103J |
|---|---|
| Mounting | Through Hole |
| Max Processing Temp | 250 to 260 |
| Lead Finish | Tin |
| Dielectric | PP |
| Termination Style | Radial |
| Rad Hard | No |
| Seated Plane Height | 13.8 mm |
| Tolerance | 5 % |
| Voltage(DC) | 1.6 kV |
| Package/Case | 20.3(Max) X 6.4(Max) X 12.3(Max) |
| Capacitance Value | 0.01 uF |
| Operating Temperature | -40 to 105 °C |
| Product Dimensions | 20.3 x 6.4 x 12.3 mm |
| Lead Pitch For Radial | 17.5 mm |
| Product Depth | 6.4(Max) mm |
| Product Height | 12.3(Max) mm |
| Product Length | 20.3(Max) mm |
| Replacement Part Number | PART-ECWHA3C103J |
| Weight | Contact us |
| Country of Origin | - |
