Please contact us for more photos of ECWFD2W334KQ
| Part Number | ECWFD2W334KQ |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 214580 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.33uF 450VDC PP 10% (12.6 X 5.6 X 15.4mm) Radial 10mm 110\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECWFD2W334KQ |
| Datasheet download |  ECWFD2W334KQ.pdf |
| Part Number | ECWFD2W334KQ |
|---|---|
| Seated Plane Height | 15.4 mm |
| Voltage(DC) | 450 V |
| Pin Count | 2 |
| Package/Case | 12.6(Max) X 5.6(Max) X 15.4(Max) |
| Construction | Radial |
| Operating Temperature | -40 to 110 °C |
| Lead Pitch For Radial | 10 mm |
| Supplier Package | Radial |
| Tolerance | 10 % |
| Capacitance Value | 0.33 uF |
| Termination Style | Radial |
| Rad Hard | No |
| Lead Finish | Tin |
| Mounting | Through Hole |
| Product Depth | 5.6(Max) mm |
| Product Height | 15.4(Max) mm |
| Product Length | 12.6(Max) mm |
| Replacement Part Number | PART-ECWFD2W334KQ |
| Weight | Contact us |
| Country of Origin | - |
