Please contact us for more photos of ECQE2684JBB
| Part Number | ECQE2684JBB |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 182600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.68uF 250V PET 5% (12.3 X 7.3 X 17.7mm) Radial 5mm 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECQE2684JBB |
| Datasheet download |  ECQE2684JBB.pdf |
| Part Number | ECQE2684JBB |
|---|---|
| Termination Style | Radial |
| Mounting | Through Hole |
| Type | Radial |
| Seated Plane Height | 17.7 mm |
| Product Dimensions | 12.3 x 7.3 x 17.7 mm |
| Lead Pitch For Radial | 5 mm |
| Lead Finish | Tin |
| Tolerance | 5 % |
| Max Processing Temp | 250 to 260 |
| Package/Case | 12.3(Max) X 7.3(Max) X 17.7(Max) |
| Rad Hard | No |
| Voltage(DC) | 250 V |
| Operating Temperature | -40 to 105 °C |
| Dielectric Material | PET |
| Capacitance Value | 0.68 uF |
| Dielectric | PET |
| Product Depth | 7.3(Max) mm |
| Product Height | 17.7(Max) mm |
| Product Length | 12.3(Max) mm |
| Replacement Part Number | PART-ECQE2684JBB |
| Weight | Contact us |
| Country of Origin | - |
