Please contact us for more photos of AXK860145WG
| Part Number | AXK860145WG |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 819350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board HDR 60 POS 0.4mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | AXK860145WG |
| Datasheet download |  AXK860145WG.pdf |
| Part Number | AXK860145WG |
|---|---|
| Termination Method | Solder |
| Mounting | Surface Mount |
| Pitch | 0.4 mm |
| Gender | HDR |
| Housing Color | Black |
| Body Orientation | Straight |
| Product Dimensions | 13.1 x 3.12 x 1.31 mm |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Over Nickel |
| Lead Finish | Gold |
| Operating Temperature | -55 to 85 °C |
| Rad Hard | No |
| Housing Material | Liquid Crystal Polymer |
| Product Depth | 3.12 mm |
| Product Height | 1.31 mm |
| Product Length | 13.1 mm |
| Replacement Part Number | PART-AXK860145WG |
| Weight | Contact us |
| Country of Origin | - |
