Part Number | 640454-6 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 507240 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Wire to Board HDR 6 POS 2.54mm Solder ST Thru-Hole |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 640454-6 |
Datasheet download | ![]() |
Part Number | 640454-6 |
---|---|
Max Processing Temp | 240|260|265 |
Lead Finish | Tin |
Family Name | Mass Termination Assembly (MTA) Connectors |
Pitch | 2.54 mm |
Contact Plating | Tin |
Contact Material | Copper Alloy |
Maximum Voltage Rating | 250 |
Housing Color | White |
Body Orientation | Straight |
Number of Rows | 1 |
Mounting | Through Hole |
Type | Wire to Board |
Product Dimensions | 15.24 x 5.72 x 10.03 mm |
Maximum Contact Resistance | 6 |
Maximum Current Rating | 5/Contact |
Gender | HDR |
Housing Material | Polyester |
Termination Method | Solder |
Rad Hard | No |
Operating Temperature | -55 to 105 °C |
Product Depth | 5.72 mm |
Product Height | 10.03 mm |
Product Length | 15.24 mm |
Replacement Part Number | PART-640454-6 |
Weight | Contact us |
Country of Origin | - |
