SUP90P06-09L-E3 Vishay

SUP90P06-09L-E3 Images

Please contact us for more photos of SUP90P06-09L-E3

Part Number SUP90P06-09L-E3
Manufacturer Vishay
Quantity in stock 296660 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET P-CH 60V 90A 3-Pin(3+Tab) TO-220AB
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level SUP90P06-09L-E3
Datasheet download SUP90P06-09L-E3.pdf
Request Quotation for SUP90P06-09L-E3

SUP90P06-09L-E3 Specifications

Part Number SUP90P06-09L-E3
Maximum Drain Source Voltage 60 V
Product Dimensions 10.41 x 4.7 x 9.01 mm
Operating Temperature -55 to 175 °C
Supplier Package TO-220AB
Typical Turn-Off Delay Time 140 ns
Rad Hard No
Typical Rise Time 190 ns
Max Processing Temp 260
Maximum Continuous Drain Current 90 A
Channel Type P
Channel Mode Enhancement
Lead Finish Matte Tin
RDS-on 9.3@10V mOhm
Typical Turn-On Delay Time 20 ns
Mounting Through Hole
MSL Level 1
Pin Count 3
Typical Fall Time 300 ns
Maximum Gate Source Voltage ±20 V
Package 3TO-220AB
Replacement Part Number PART-SUP90P06-09L-E3
Weight Contact us
Country of Origin -
