Please contact us for more photos of 0901310769
| Part Number | 0901310769 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 777910 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 18 POS 2.54mm Solder ST Thru-Hole Bag |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0901310769 |
| Datasheet download |  0901310769.pdf |
| Part Number | 0901310769 |
|---|---|
| Termination Method | Solder |
| Product Dimensions | 22.86 x 5.08 x 9.25 mm |
| Contact Plating | Gold |
| Housing Color | Black |
| Mounting | Through Hole |
| Gender | HDR |
| Body Orientation | Straight |
| Lead Finish | Tin |
| Contact Material | Brass |
| Operating Temperature | -55 to 125 °C |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Housing Material | Polyester |
| Product Depth | 5.08 mm |
| Product Height | 9.25 mm |
| Product Length | 22.86 mm |
| Replacement Part Number | PART-0901310769 |
| Weight | Contact us |
| Country of Origin | - |
