Please contact us for more photos of 0015474107
| Part Number | 0015474107 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 725200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn IDC Connector F 10 POS 2.54mm IDT ST Cable Mount Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0015474107 |
| Datasheet download |  0015474107.pdf |
| Part Number | 0015474107 |
|---|---|
| Body Orientation | Straight |
| Housing Color | Black |
| Lead Finish | Tin |
| Operating Temperature | -40 to 105 °C |
| Product Dimensions | 25.37 x 15.24 x 6.6 mm |
| Termination Method | IDT |
| Contact Plating | Gold Over Nickel |
| Contact Material | Phosphor Bronze |
| Gender | F |
| Housing Material | Polyester |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Mounting | Cable Mount |
| Product Depth | 15.24 mm |
| Product Height | 6.6 mm |
| Product Length | 25.37 mm |
| Replacement Part Number | PART-0015474107 |
| Weight | Contact us |
| Country of Origin | - |
