Please contact us for more photos of MAX17543ATP+T
| Part Number | MAX17543ATP+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 261160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V to 42V 20-Pin TQFN EP T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | MAX17543ATP+T |
| Datasheet download |  MAX17543ATP+T.pdf |
| Part Number | MAX17543ATP+T |
|---|---|
| Lead Finish | Matte Tin |
| Efficiency | 90 % |
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Number of Outputs | 1 |
| Screening Level | Automotive |
| Pin Count | 20 |
| Switching Regulator | Yes |
| Maximum Input Voltage | 42 V |
| Operating Temperature | -40 to 125 °C |
| Output Voltage | 0.9 to 37.8 V |
| Supplier Package | TQFN EP |
| Product Dimensions | 4 x 4 x 0.73 |
| Type | Step Down |
| Switching Frequency | 2200 kHz |
| Output Type | Adjustable |
| Operating Supply Voltage | 4.5 to 42 V |
| Maximum Output Current | 2.5 A |
| Minimum Input Voltage | 4.5 V |
| Max Processing Temp | 260 |
| Package | 20TQFN EP |
| Replacement Part Number | PART-MAX17543ATP+T |
| Weight | Contact us |
| Country of Origin | - |
