Please contact us for more photos of TLE4253GS
| Part Number | TLE4253GS |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 431160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LDO Regulator Pos 2V to 45V 0.25A 8-Pin DSO T R |
| Category | Power Management IC |
| Family | Low Dropout Controller |
| ROHS Compliant | Yes |
| MSL Level | TLE4253GS |
| Datasheet download |  TLE4253GS.pdf |
| Part Number | TLE4253GS |
|---|---|
| Pin Count | 8 |
| Junction to Ambient | 150 K/W |
| Maximum Output Current | 0.25 A |
| Accuracy | ±0.5 % |
| Output Type | Adjustable |
| Maximum Quiescent Current | 0.15 mA |
| Polarity | Positive |
| Minimum Input Voltage | 3.5 V |
| Typical Quiescent Current | 0.12 mA |
| Input Voltage Range | 3.5 to 40 V |
| Maximum Dropout Voltage @ Current | 0.6@200mA V |
| Operating Temperature | -40 to 150 °C |
| Maximum Input Voltage | 40 V |
| Typical Dropout Voltage @ Current | 0.28@200mA V |
| Rad Hard | No |
| Line Regulation | 10 mV |
| Supplier Package | DSO |
| Product Dimensions | 5 x 4 x 1.45 |
| Load Regulation | 10 mV |
| Number of Outputs | 1 |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Lead Finish | Tin |
| MSL Level | 3 |
| Reference Voltage | 2 V |
| Output Voltage | 2 to 45 V |
| Screening Level | Automotive |
| Function | LDO |
| Package | 8DSO |
| Replacement Part Number | PART-TLE4253GS |
| Weight | Contact us |
| Country of Origin | - |
