Please contact us for more photos of W3A45A470KAT2A
| Part Number | W3A45A470KAT2A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 134600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic Array 47pF 50V C0G 10% 0612 SMD 4 Capacitor 125\u00b0C Paper T R Embossed T R |
| Category | Capacitors |
| Family | Capacitor Array |
| ROHS Compliant | Yes |
| MSL Level | W3A45A470KAT2A |
| Datasheet download |  W3A45A470KAT2A.pdf |
| Part Number | W3A45A470KAT2A |
|---|---|
| Package/Case | 0612 |
| Operating Temperature | -55 to 125 °C |
| Case Size | 0612 |
| Product Dimensions | 1.6 x 3.2 x 1.35 mm mm |
| Terminal Pitch | 0.76 mm |
| Dielectric | C0G |
| Rad Hard | No |
| Number of Capacitors | 4 |
| Number of Terminals | 8 |
| Dielectric Material | Ceramic |
| Voltage(DC) | 50 V |
| Capacitance Value | 47 pF |
| Tolerance | 10 % |
| Max Processing Temp | 260 °C |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Construction | Flat |
| Product Depth | 3.2 mm |
| Product Height | 1.35(Max) mm |
| Product Length | 1.6 mm |
| Replacement Part Number | PART-W3A45A470KAT2A |
| Weight | Contact us |
| Country of Origin | - |
