Please contact us for more photos of 10052837-101LF
| Part Number | 10052837-101LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 273370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Backplane HDR 96 POS 2mm Press Fit RA Thru-Hole |
| Category | Connectors |
| Family | Connector Backplane |
| ROHS Compliant | Yes |
| MSL Level | 10052837-101LF |
| Datasheet download |  10052837-101LF.pdf |
| Part Number | 10052837-101LF |
|---|---|
| Rad Hard | No |
| Body Orientation | Right Angle |
| Product Dimensions | 15.9 x 33.8 x 19.7 mm |
| Housing Color | Black |
| Lead Finish | Tin |
| Gender | HDR |
| Contact Material | Copper Alloy |
| Housing Material | Thermoplastic |
| Number of Rows | 12 |
| Mounting | Through Hole |
| Termination Method | Press Fit |
| Pitch | 2 mm |
| Max Processing Temp | 260 |
| Type | Backplane |
| Number of Contacts | 96 |
| Contact Plating | Gold Over Nickel |
| Product Depth | 33.8 mm |
| Product Height | 19.7 mm |
| Product Length | 15.9 mm |
| Replacement Part Number | PART-10052837-101LF |
| Weight | Contact us |
| Country of Origin | - |
