Please contact us for more photos of 536019-5
| Part Number | 536019-5 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 835210 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn DIN 41612 PIN 96 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Backplane |
| ROHS Compliant | Yes |
| MSL Level | 536019-5 |
| Datasheet download |  536019-5.pdf |
| Part Number | 536019-5 |
|---|---|
| Termination Method | Solder |
| Type | DIN 41612 |
| Number of Rows | 3 |
| Mounting | Through Hole |
| Gender | PIN |
| Body Orientation | Straight |
| Operating Temperature | -55 to 125 °C |
| Number of Contacts | 96 |
| Housing Color | Gray |
| Product Dimensions | 95 x 11.1 x 11.51 mm |
| Rad Hard | No |
| Housing Material | Polyester |
| Pitch | 2.54 mm |
| Contact Material | Phosphor Bronze |
| Product Depth | 11.1 mm |
| Product Height | 11.51 mm |
| Product Length | 95 mm |
| Replacement Part Number | PART-536019-5 |
| Weight | Contact us |
| Country of Origin | - |
