Part Number | D2510-5002-AR |
---|---|
Manufacturer | 3M |
Quantity in stock | 156010 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Shrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | D2510-5002-AR |
Datasheet download | ![]() |
Part Number | D2510-5002-AR |
---|---|
Lead Finish | Matte Tin |
Rad Hard | No |
Number of Rows | 2 |
Contact Material | Brass |
Body Orientation | Right Angle |
Housing Material | Polychlorinated Terphenyl |
Termination Method | Solder |
MSL Level | 1 |
Housing Color | Black |
Pitch | 2.54 mm |
Gender | HDR |
Type | Shrouded Header |
Maximum Voltage Rating | 1000 V |
Operating Temperature | -55 to 105 °C |
Max Processing Temp | 260 |
Mounting | Through Hole |
Product Dimensions | 20.02 x 12.44 x 8.59 mm |
Contact Plating | Gold Over Nickel |
Product Depth | 12.44 mm |
Product Height | 8.59 mm |
Product Length | 20.02 mm |
Replacement Part Number | PART-D2510-5002-AR |
Weight | Contact us |
Country of Origin | - |
