Part Number | 6-104910-6 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 178820 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Shrouded Header HDR 17 POS 2.54mm Solder ST Thru-Hole Tube |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 6-104910-6 |
Datasheet download | ![]() |
Part Number | 6-104910-6 |
---|---|
Housing Material | Thermoplastic |
Contact Material | Brass |
Max Processing Temp | 240|245|260|265 |
Rad Hard | No |
Contact Plating | Gold Over Nickel |
Body Orientation | Straight |
Lead Finish | Tin |
Mounting | Through Hole |
Product Dimensions | 45.72 x 6.66 x 13.59 mm |
Termination Method | Solder |
Gender | HDR |
Operating Temperature | -65 to 105 °C |
Pitch | 2.54 mm |
Housing Color | Black |
Product Depth | 6.66 mm |
Product Height | 13.59 mm |
Product Length | 45.72 mm |
Replacement Part Number | PART-6-104910-6 |
Weight | Contact us |
Country of Origin | - |
