Please contact us for more photos of ZMY5V6-GS18
| Part Number | ZMY5V6-GS18 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 230920 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 5.6V 7% 1W 2-Pin MELF Glass T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | ZMY5V6-GS18 |
| Datasheet download |  ZMY5V6-GS18.pdf |
| Part Number | ZMY5V6-GS18 |
|---|---|
| Nominal Zener Voltage | 5.6 V |
| Mounting | Surface Mount |
| Typical Voltage Temperature Coefficient | 0.01 %/°C |
| Type | Voltage Regulator |
| ESD Protection | No |
| Maximum Zener Impedance | 2 Ohm |
| MSL Level | 1 |
| Maximum Power Dissipation | 1000 mW |
| Pin Count | 2 |
| Zener Voltage Tolerance | 7 % |
| Maximum Regulator Current | 135 |
| Rad Hard | No |
| Configuration | Single |
| Test Current | 100 mA |
| Max Processing Temp | 260 |
| Operating Temperature | -55 to 175 °C |
| Product Dimensions | 5.2 x 2.6 x 2.6 mm |
| Lead Finish | Tin/Silver |
| Supplier Package | MELF Glass |
| Package | 2MELF Glass |
| Replacement Part Number | PART-ZMY5V6-GS18 |
| Weight | Contact us |
| Country of Origin | - |
