Please contact us for more photos of SZBZX84B6V2LT1G
| Part Number | SZBZX84B6V2LT1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 299140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 6.2V 2% 300mW 3-Pin SOT-23 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | SZBZX84B6V2LT1G |
| Datasheet download |  SZBZX84B6V2LT1G.pdf |
| Part Number | SZBZX84B6V2LT1G |
|---|---|
| Maximum Zener Impedance | 10 Ohm |
| Mounting | Surface Mount |
| Maximum Reverse Leakage Current | 3 uA |
| Type | Voltage Regulator |
| ESD Protection | Yes |
| Supplier Package | SOT-23 |
| MSL Level | 1 |
| Zener Voltage Tolerance | 2 % |
| Pin Count | 3 |
| Screening Level | Automotive |
| Typical Voltage Temperature Coefficient | 2.05 mV/K |
| Product Dimensions | 2.9 x 1.3 x 0.94 mm |
| Nominal Zener Voltage | 6.2 V |
| Rad Hard | No |
| Configuration | Single |
| Max Processing Temp | 260 |
| Maximum Power Dissipation | 300 mW |
| Operating Temperature | -65 to 150 °C |
| Test Current | 5 mA |
| Package | 3SOT-23 |
| Replacement Part Number | PART-SZBZX84B6V2LT1G |
| Weight | Contact us |
| Country of Origin | - |
