Please contact us for more photos of SMAZ5931B-E3C H
| Part Number | SMAZ5931B-E3C H |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 107050 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 18V \u00b15% 1500mW 2-Pin DO-214AC |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | SMAZ5931B-E3C H |
| Datasheet download |  SMAZ5931B-E3C H.pdf |
| Part Number | SMAZ5931B-E3C H |
|---|---|
| Package Dimensions | 4.5 x 2.79 x 2.29 mm |
| Pin Count | 2 |
| Zener Voltage Tolerance | ±5 % |
| Maximum Regulator Current | 83 |
| Test Current | 20.8 mA |
| Supplier Package | DO-214AC |
| Maximum Reverse Leakage Current | 1 uA |
| Nominal Zener Voltage | 18 V |
| Type | Voltage Regulator |
| Lead Finish | Matte Tin |
| Maximum Power Dissipation | 1500@Tl=75C mW |
| Rad Hard | No |
| Configuration | Single |
| Moisture Sensitivity Level | 1 |
| Maximum Processing Temperature | 260 °C |
| ESD Protection | Yes |
| Mounting | Surface Mount |
| Maximum Zener Impedance | 12 Ohm |
| Operating Temperature | -65 to 150 °C |
| Package | 2DO-214AC |
| Replacement Part Number | PART-SMAZ5931B-E3C H |
| Weight | Contact us |
| Country of Origin | - |
