Please contact us for more photos of MMSZ5242B-7-F
| Part Number | MMSZ5242B-7-F |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 389050 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 12V 5% 500mW 2-Pin SOD-123 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MMSZ5242B-7-F |
| Datasheet download |  MMSZ5242B-7-F.pdf |
| Part Number | MMSZ5242B-7-F |
|---|---|
| Pin Count | 2 |
| Configuration | Single |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Nominal Zener Voltage | 12 V |
| Operating Temperature | -65 to 150 °C |
| Lead Finish | Matte Tin |
| Supplier Package | SOD-123 |
| Test Current | 20 mA |
| Product Dimensions | 2.85 x 1.7 x 1.35 mm |
| Zener Voltage Tolerance | 5 % |
| Mounting | Surface Mount |
| Maximum Power Dissipation | 500 mW |
| Maximum Zener Impedance | 30 Ohm |
| Screening Level | Commercial |
| MSL Level | 1 |
| Maximum Reverse Leakage Current | 1 uA |
| ESD Protection | No |
| Package | 2SOD-123 |
| Replacement Part Number | PART-MMSZ5242B-7-F |
| Weight | Contact us |
| Country of Origin | - |
