Please contact us for more photos of CRZ13(TE85L,Q,M)
| Part Number | CRZ13(TE85L,Q,M) |
|---|---|
| Manufacturer | Toshiba |
| Quantity in stock | 638510 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 13V 10% 700mW 2-Pin S-FLAT T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | CRZ13(TE85L,Q,M) |
| Datasheet download |  CRZ13(TE85L,Q,M).pdf |
| Part Number | CRZ13(TE85L,Q,M) |
|---|---|
| Maximum Reverse Leakage Current | 10 uA |
| Supplier Package | S-FLAT |
| Product Dimensions | 2.6 x 1.6 x 0.98 mm |
| Nominal Zener Voltage | 13 V |
| Rad Hard | No |
| Pin Count | 2 |
| Zener Voltage Tolerance | 10 % |
| Configuration | Single |
| Mounting | Surface Mount |
| Maximum Power Dissipation | 700 mW |
| Maximum Zener Impedance | 30 Ohm |
| Typical Voltage Temperature Coefficient | 9 mV/°C |
| Operating Temperature | -40 to 150 °C |
| ESD Protection | No |
| Test Current | 10 mA |
| Type | Voltage Regulator |
| Package | 2S-FLAT |
| Replacement Part Number | PART-CRZ13(TE85L,Q,M) |
| Weight | Contact us |
| Country of Origin | - |
