BZX84C16-7-F Diodes Incorporated

BZX84C16-7-F Images

Please contact us for more photos of BZX84C16-7-F

Part Number BZX84C16-7-F
Manufacturer Diodes Incorporated
Quantity in stock 543770 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Zener Single 16V 6% 350mW 3-Pin SOT-23 T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level BZX84C16-7-F
Datasheet download BZX84C16-7-F.pdf
Request Quotation for BZX84C16-7-F

BZX84C16-7-F Specifications

Part Number BZX84C16-7-F
Nominal Zener Voltage 16 V
Operating Temperature -65 to 150 °C
Screening Level Commercial
Test Current 5 mA
Maximum Power Dissipation 350 mW
Max Processing Temp 260
Product Dimensions 2.9 x 1.3 x 1 mm
Maximum Reverse Leakage Current 0.1 uA
Typical Voltage Temperature Coefficient 12.2 mV/°C
Configuration Single
ESD Protection No
Lead Finish Matte Tin
Rad Hard No
Mounting Surface Mount
Supplier Package SOT-23
MSL Level 1
Zener Voltage Tolerance 6 %
Maximum Zener Impedance 40 Ohm
Pin Count 3
Package 3SOT-23
Replacement Part Number PART-BZX84C16-7-F
Weight Contact us
Country of Origin -
