Please contact us for more photos of BZG03C10TR
| Part Number | BZG03C10TR |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 847610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 10V 6% 3W 2-Pin SMA T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BZG03C10TR |
| Datasheet download |  BZG03C10TR.pdf |
| Part Number | BZG03C10TR |
|---|---|
| Lead Finish | Matte Tin |
| Supplier Package | SMA |
| Typical Voltage Temperature Coefficient | 0.07 %/K |
| Product Dimensions | 4.6 x 2.9 mm |
| Mounting | Surface Mount |
| Nominal Zener Voltage | 10 V |
| Type | Voltage Regulator |
| Maximum Zener Impedance | 4 Ohm |
| Zener Voltage Tolerance | 6 % |
| MSL Level | 1 |
| ESD Protection | No |
| Maximum Power Dissipation | 3000@Ta=100C mW |
| Pin Count | 2 |
| Test Current | 50 mA |
| Rad Hard | No |
| Configuration | Single |
| Max Processing Temp | 260 |
| Operating Temperature | -65 to 150 °C |
| Maximum Reverse Leakage Current | 10 uA |
| Package | 2SMA |
| Replacement Part Number | PART-BZG03C10TR |
| Weight | Contact us |
| Country of Origin | - |
