Part Number | XC3S50AN-4TQG144I |
---|---|
Manufacturer | Xilinx |
Quantity in stock | 776780 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | FPGA Spartan\u00ae-3AN Family 50K Gates 1584 Cells 667MHz 90nm Technology 1.2V 144-Pin TQFP |
Category | Programmable Logic IC |
Family | FPGA |
ROHS Compliant | Yes |
MSL Level | XC3S50AN-4TQG144I |
Datasheet download | ![]() |
Part Number | XC3S50AN-4TQG144I |
---|---|
Lead Finish | Matte Tin |
Operating Temperature | -40 to 100 °C |
Mounting | Surface Mount |
Fabrication Technology | 90nm |
Maximum Number of User I/Os | 108 |
Device System Gates | 50000 |
Re-programmability Support | Yes |
Typical Operating Supply Voltage | 1.2 V |
Maximum Internal Frequency | 667 MHz |
Screening Level | Industrial |
Maximum Operating Supply Voltage | 1.26 V |
Pin Count | 144 |
Device Logic Units | 1584 |
RAM Bits | 55296 |
In System Programmability | Yes |
Device Logic Gates | 50000 |
Supplier Package | TQFP |
Device Logic Cells | 1584 |
Rad Hard | No |
Product Dimensions | 20 x 20 x 1.4 mm |
Max Processing Temp | 260 |
Speed Grade | 4 |
Number of Registers | 176 |
Minimum Operating Supply Voltage | 1.14 V |
MSL Level | 3 |
Package | 144TQFP |
Replacement Part Number | PART-XC3S50AN-4TQG144I |
Weight | Contact us |
Country of Origin | - |
