Please contact us for more photos of TL594IDR
| Part Number | TL594IDR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 267600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Voltage Mode PWM Controller 40V 200mA 16-Pin SOIC T R |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | TL594IDR |
| Datasheet download |  TL594IDR.pdf |
| Part Number | TL594IDR |
|---|---|
| On/Off Pin | No |
| Lead Finish | Gold |
| Output Voltage | 40 Vdc |
| Maximum Duty Cycle | 45(Min) % |
| Fall Time | 45 ns |
| Synchronous Pin | No |
| Rise Time | 200 ns |
| Operating Supply Voltage | 3.3|5 |
| Topology | Boost|Flyback|Forward|Push-Pull |
| Adjustable Output | No |
| Supplier Package | SOIC |
| Pin Count | 16 |
| Output Current | 200 mA |
| Switching Frequency | 300 kHz |
| Product Dimensions | 10 x 4 x 1.5 mm |
| Number of PWM Outputs | 2 |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Package | 16SOIC |
| Replacement Part Number | PART-TL594IDR |
| Weight | Contact us |
| Country of Origin | - |
