Please contact us for more photos of WSK2512R0100FEA
| Part Number | WSK2512R0100FEA |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 227590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Metal Strip 2512 0.01 Ohm 1% 1W \u00b135ppm \u00b0C Molded SMD SMD T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | WSK2512R0100FEA |
| Datasheet download |  WSK2512R0100FEA.pdf |
| Part Number | WSK2512R0100FEA |
|---|---|
| Max Processing Temp | 260 |
| Rad Hard | No |
| Case Style | Molded |
| Product Dimensions | 6.35 x 3.18 x 0.635 mm |
| Case Size | 2512 |
| Resistance Value | 10 MOhm |
| Temperature Coefficient | ±35 ppm/°C |
| Power Rating | 1 W |
| Mounting | Surface Mount |
| Operating Temperature | -65 to 170 °C |
| Lead Finish | Tin |
| MSL Level | 1 |
| Tolerance | 1 % |
| Product Depth | 3.18 mm |
| Product Height | 0.635 mm |
| Product Length | 6.35 mm |
| Product Weight | 63.6 mg |
| Replacement Part Number | PART-WSK2512R0100FEA |
| Weight | Contact us |
| Country of Origin | - |
