Please contact us for more photos of VJ1206A220JXJCW1BC
| Part Number | VJ1206A220JXJCW1BC |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 602700 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 22pF 16V C0G 5% SMD 1206 125\u00b0C Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | VJ1206A220JXJCW1BC |
| Datasheet download |  VJ1206A220JXJCW1BC.pdf |
| Part Number | VJ1206A220JXJCW1BC |
|---|---|
| Tolerance | 5 % |
| Case Style | Ceramic Chip |
| Construction | Flat |
| Case Size | 1206 |
| Lead Finish | Matte Tin |
| Product Dimensions | 3.2 x 1.6 x 1.9 mm |
| Max Processing Temp | 235 to 260|260 |
| Rad Hard | No |
| Package/Case | 1206 |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Dielectric | C0G |
| Operating Temperature | -55 to 125 °C |
| Capacitance Value | 22 pF |
| Voltage(DC) | 16 V |
| Product Depth | 1.6 mm |
| Product Height | 1.9(Max) mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-VJ1206A220JXJCW1BC |
| Weight | Contact us |
| Country of Origin | - |
