Please contact us for more photos of TMCP1D104MTRF
| Part Number | TMCP1D104MTRF |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 484990 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 0.1uF 20V P CASE 20% (2 X 1.25 X 1.2mm) SMD 2012-12 33 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TMCP1D104MTRF |
| Datasheet download |  TMCP1D104MTRF.pdf |
| Part Number | TMCP1D104MTRF |
|---|---|
| Pin Count | 2 |
| Package/Case | 2012-12,P |
| Polarity | Polar |
| MSL Level | 1 |
| Case Size | 0805 |
| Case Style | Molded |
| Rad Hard | No |
| Dissipation Factor | 6 % |
| Case Code | P |
| Equivalent Series Resistance | 33 Ohm |
| Voltage(DC) | 20 V |
| Tolerance | 20 % |
| Operating Temperature | -55 to 125 °C |
| Product Dimensions | 2 x 1.25 x 1.2(Max) |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Supplier Package | 0805 |
| Lead Finish | Matte Tin |
| Leakage Current | 0.5 uA |
| Capacitance Value | 0.1 uF |
| Construction | Flat |
| Product Depth | 1.25 mm |
| Product Height | 1.2(Max) mm |
| Product Length | 2 mm |
| Replacement Part Number | PART-TMCP1D104MTRF |
| Weight | Contact us |
| Country of Origin | - |
