Please contact us for more photos of SMBJ7.5AHE3 52
| Part Number | SMBJ7.5AHE3 52 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 406410 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Uni-Dir 7.5V 600W 2-Pin SMB T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SMBJ7.5AHE3 52 |
| Datasheet download |  SMBJ7.5AHE3 52.pdf |
| Part Number | SMBJ7.5AHE3 52 |
|---|---|
| Configuration | Single |
| Mounting | Surface Mount |
| Maximum Reverse Stand-off Voltage | 7.5 V |
| Maximum Reverse Leakage Current | 100 uA |
| Direction Type | Uni-Directional |
| Supplier Package | SMB |
| Test Current | 1 |
| Peak Pulse Power Dissipation | 600 |
| Rad Hard | No |
| Maximum Peak Pulse Current | 46.5 A |
| MSL Level | 1 |
| Product Dimensions | 4.7 x 3.8 mm |
| Max Processing Temp | 260 |
| Pin Count | 2 |
| Lead Finish | Matte Tin |
| Operating Temperature | -55 to 150 °C |
| Maximum Clamping Voltage | 12.9 V |
| Minimum Breakdown Voltage | 8.33 V |
| ESD Protection | No |
| Package | 2SMB |
| Replacement Part Number | PART-SMBJ7.5AHE3 52 |
| Weight | Contact us |
| Country of Origin | - |
